TrueHD-640 Series Indoor Fine Pixel in 1.25/1.37/1.53/1.86/2.0/2.5 mm LED Display 640x480 mm Aluminum Cabinet Small Pixel Pitch LED Display Screen
Unit Price Here is Per One Square Meter, Standard Version
Click to Download Full Catalog of Fine Pixel Pitch LED Display Screen
Features:
* Fine Pixel Pitch produce high resolution pictures
* IP30 at Front and Back
* Cabinet Size 640x480mm
* 160 ° Wide Viewing Angle
* Intelligent Correction
* Remove Colored Moire
* None-wire Connected Cabinet, More Humanized Design
* Front/Rear Installation; Front Maintenance
TrueHD-640 Series Series Indoor LED Display Specification
PART NUMBER BREAKDOWN
HD640-1.25: HD【Series Code : High Definition 】- 640【Cabinet length: 640mm】- 1.2【Pixel Pitch: 1.25mm】
Part No.: HD640-1.25 | HD640-1.37 | HD640-1.53 | HD640-1.86 | HD640-2.0 | HD640-2.5
Pixel Pitch: 1.25mm | 1.379mm | 1.538mm | 1.86mm | 2.0mm | 2.5mm
LED : SMD1010 | SMD1010 | SMD1010 | SMD1515 | SMD1515 | SMD1515
LED Brand: Standard: Kinglight/Huaguang etc. Premium:Nationstar
Pixel Configuration : 1R 1G 1B
Wave Length: R:620~625nm, G:520~530nm, B:460~475nm
Module
Module Size: 320*160mm
Module Resolution: 256*128 | 232*116 | 208*104 | 172*86 | 160*80 | 128*64
Module Pixles: 32768dots | 26918dots | 21632dots | 14792dots | 12800dots | 8192dots
Scan: 1/32 | 1/58 | 1/52 | 1/43 | 1/40 | 1/32
Viewing Distance: >1.5m | >1.5m | >1.5m | >2m | >2m | >2.5m
Cabinet
Cabinet Type: Die-casting Aluminum
Cabinet Size: 640*480*75mm
Module Qty./Cabinet: 6
Cabinet Qty./㎡: 3.26
Cabinet Resolution: 512*384 | 464*348 | 416*312 | 344*258 | 320*240 | 256*192
Cabinet Pixles: 196608dots | 161472dots | 129792dots | 88752dots | 76800dots | 49152dots
Pixel Density : 640,000dots/㎡ | 526,398dots/㎡ | 423,122dots | 289,332dots | 250,368dots/㎡ | 160,234dots/㎡
Power Consumption: Max.850W/㎡ Avg.285W/㎡
Optical Parameter
Brightness: 800cd/㎡
Contrast Rate: 3000:1
Color Depth: 16bit
Grey Level: 16384
Refresh Frequency: >3840HZ
Driving IC: MBI/ICN
Color Uniformity: ≥97%
Viewing Angle: H:160deg. V:160deg.
Blind Spot Rate: ≤0.0003
Life span: ≥100,000 hours
Physical Parameter & Operation Conditions
Cabinet Weight : 9Kgs
Protection Rating: IP30
Operating Temperature : -20°C ~ 60°C(-4°F ~ 140°F)
Operating Humidity: 10% ~ 90%
Input voltage: AC100-240V
Power Supply : Standard: CE*1 / Premium:UL CE MeanWell *1
Controlling System: Nova
Maintainance : Front / Rear Installation; Front Maintenance
