Description
Mooncell Receiving CardT30
Features:
1.It features Solder Joints Interfaces : 38 PIN is horizontal & 24 PIN is vertical
2.It is upgrading-free and compatible with a variety of driver ICs
3.It supports the pixel-level brightness&chroma calibrations and the low grey scale can be compensated
4.Dual receiving cards backup ( Dual Circuits backup), Network Cable Hot Backup(Online Backup), Dual Power Supplies Backup
5.It supports to detect the error rates of the network cable & the serial # of the receiving card
6.It supports to repair the configuration parameters with just one click ( Smart Repair)
7.It supports to have the user-defined data interface
8.The Images on the led screen can be rotated 90 degree in a factor of multi times and also can be zoomed in & out
9.It supports to read the configuration data back from where it's been stored
10.The calibration data will be automatically write in when the module is replaced
11.It is RoHS & CE-EMC compliant
Loading Specs:
1.Parallel Data (RGB): 26 Dataset
2.Serial Data: 78 Dataset
3.The maximum loading capac-ity(pixels):256*384
4.The quantity of the receiving cards that it can be cascading connected:≤1000PCS
5.The scanning line supported:1-128 Lines
6.The maximum loading capacity in
