Description
Wavelength: 395nm-405nm
IP Grade avaliable : Non-Waterproof , IP65 Waterproof , IP67 Waterproof , IP68 Waterproof
395nm-405nm SMD5050-600 12V DC <12W, 144Amp UV (Ultraviolet) LED Strip Light Non-Waterproof Flexible White PCB Strip Light Ideal for UV Curing, Currency Validation, Mosquito killer, Fluorescence disclosing and Medical Field
Note: Sold by Different Lengths in 50cm, 100cm, 200cm, 300cm, 400cm, 500cm.
Available Lengths and Suggested Power Supply to power (the power supply is not included)
| Length | Wattage (w) | Suggested Power Supply |
| 50cm |
8 |
12V, 1Amp, 12W |
| 100cm |
16 |
12V, 2Amp, 24W |
| 200cm | 32 | 12V, 3.0Amp, 36W |
| 300cm | 48 | 12V, 5.0Amp, 60W |
| 400cm | 64 | 12V, 6Amp, 72W |
| 500cm | 80 | 12V, 8Amp,96W |
To use bigger power supply than rated power of the strip is to avoid full loaded working, which is better for the lifespan of the Power Supply.
Strip Light Specification for 5 Meter Roll
LED Type: UV SMD5050
LED QTY.: 120LED/Meter
Input Voltage: 12V DC
Wattage (max): 28.8Watt/Meter
Cuttable: Every 6LED per 2'' can be cut
Size(W*H/mm): 15*1.8
Weight: 0.125kgs per 5meter per roll
Wavelength: 395nm-400nm
PCB Background color: White
PCB Backing: Double-sided Adhesive backing
Beam Angle: 120°
Dimming: PWM dimmable(more information please refer to different Dimmer applications)
Waterproof Type: Non-waterproof(indoor use)
Pre-wiring: 20cm Red/Black Lead wire at one end of the strip
UV LED Lights Application
